Specifications
Langth of CAT-5E/CAT-6 cable between Rx and TX......................................up to 120 meters
HDMI input.....................................................................................................4K/1080p/720p/576p/576i/480p480i
Support audio format.....................................................................................DTS/Dolby/LPCM
HDMI output...................................................................................................4K/1080p/720p/576p/576i/480p/480i
Max bandwidth...............................................................................................340MHz
Max baud rate.................................................................................................3.4Gbpsx3
Input video signal............................................................................................0.5∼1.5Volts p-p
Output DDC singal.........................................................................................5Volts p-p (TTL)
Input HDMI cable distance............................................................................≤15m AWG26 HDMI standard cable
Output HDMI cable distance.........................................................................≤15m AWG26 HDMI standard cable
TX Max working current................................................................................350mA
RX Max working current................................................................................200mA
Power adapter format.........................................................................Input:AC (50HZ,60HZ) 100V-24V; Output: DC5V/1A
Operating Temperature range......................................................................(-15 to +55°C)
Operating Humidity rang..............................................................................5% to 90% RH (No Condensation)
Dimension (L x W x H)...........................................................................94x84x24(mm)
TX Weight..............................................................................................223g
RX Weight.............................................................................................223g
